LiveTrac PT10 Professional

PT-10 Professional Specifications:

Device Specs:

4G LTE CAT M1 - Highly Efficient LTE

GPS Receiver Chipset: GPS/GLONASS/Galileo/QZSS

GPS Channels: 33 Tracking/ 99 Acquistion/210 PRN

Position Accuracy: 8 foot Circular Error Probable (CEP).

Time To First Fix Cold Start:<32 seconds.

Time To First Fix Hot Start: <2 seconds.

Sensitivity Acquisition: -149 dBm.

Sensitivity Tracking: -167 dBm.

Operating Temperatures: -40 Degrees F to 185 Degrees F

Device Battery Specs:

Includes Removable Internal Battery: 1400 mAh 3.7v - 8 motion hours

Includes External 9200 mAh Battery Pack: 75 motion hours

External Battery Charge Time: 9 hrs to full charge

Operating time is based on motion, as the device hibernates when not moving to conserve battery. The external battery pack provides on average between 60-75 hours of 10 second tracking.

LTE Coverage:

Coverage: ATT 4G LTE CAT M1 Network

Custom Case Specs:

Dimensions: 5" Length x 4" Width x 2.75" Height

Customized Pelican Micro Case - Painted All Black

80 Pull lb Magnet - Permanently Attached

Custom Foam Inserts For Device/Battery

Battery Life Explained:

75 Motion Hours

Example 1: A vehicle that drives for 1 hour per day of actual drive time, battery will last 75 days, before needing to be recharged.

To Calculate how many days it will last for you.

1. Determine how many hours per day the vehicle will be driving (actually in motion, as our PT-10 hibernates when not moving to conserve battery)

2. Divide the Hours Driven Per Day by 75.

3. This gives you the # of days, before needing to recharge. 3 hrs driving per day/75 hr rated battery = 25 days of driving on a single charge.

Average Daily Driving Estimated Battery Life:

1 Hr Per Day 75 Days

2 Hrs Per Day 37 Days

4 Hrs Per Day 18 Days

8 Hrs Per Day 9 Days
